High Speed Flute Laminator-factory
Tangshan UANCHOR Automation Technology Co., Ltd.
Your Professional Paper Cutting System Manufacturer!
Wide Product Range
Continuous Innovation
Rich Experience
Reliable Product Quality
Description
Tangshan UANCHOR Automation Technology Co., Ltd.
Tangshan UANCHOR Automation Technology Co., Ltd. (former Yutian Yongheng Machinery Factory) established in 2006 is the first professional poker cards machine manufacturer in China. The company developed into an integrated industrial company including designing, production, sales, and service in less than four years.
The main products are card-producing machines, pile turners, ink-jet printing machines, and inspection machines. The card-producing machines include an automatic card slitting & collating machine, an automatic photoelectric separating and checking machine, an automatic wrapping machine, and an automatic plastic box packing machine for cards.
In these years, the company has insisted on self-dependent innovation and has developed new products with advanced designs and techniques according to requirements. UANCHOR has had 5 national patents from 2009 to 2010.
The company covers 35600 square meters and buildings of more than 20000 square meters. Our company currently has 120 employees, including 20 engineers with bachelor's degrees or above and 10 engineers with more than 15 years of design experience.
With advanced manufacturing machines and testing machines, we can assure the quality of our product. The main products have obtained CE certificates.
Flute Laminator for Sale Display
Automatic High Speed Laminating Machine can automatically adjust paper size. Four servo motors realize linkage by bus control through a motion controller, which is precise, high-speed, and reliable.
The maximum mounting speed of High Speed Flute Laminating Machine is 160m/min. It realize automatic adjustment of paper size and the unique side gauge device (patent) is fast and stable.
The Flute Laminating Machine can adjust the paper size automatically. Four servo motors realize linkage by bus control through a motion controller, which is precise, high-speed, and reliable. If you need a flute laminating machine, feel free to contact us.
The maximum mounting speed of the Flute Laminator Machine is 160m/min. It adopts a unique side gauge device (patent), which is fast, stable, and can offer great convenience.
The maximum mounting speed of the Flute Laminator Machine is 160m/min. It adopts a unique side gauge device (patent), which is fast, stable, and can offer great convenience.
The Automatic Flute Laminator is suitable for laminating color printing facial paper and corrugated paper, laminating color printing facial paper and gray board paper. The bottom paper suction realizes an automatic feeding system and the top face paper can rise automatically
The Flute Laminator is mainly used to laminate linerboards to the flutes of corrugated board or laminate one cardboard to another cardboard with adhesive. Laminating sheets add a layer of clear plastic which protect the laminated material from smudges, stains, and liquids.
Common Types of Laminators
Hot Pouch Laminators
Hot Pouch Laminators are the most popular type of laminator used to encapsulate a document within a pouch which has 2 connected sides in which the item to be laminated is positioned. The pouch is coated with a heat-activated film, which melts when passed through the heated rollers and is then bonded under pressure, removing all of the bubbles and creating a tight seal.
Cold Pouch Laminators
Cold Pouch Lamination are the best option when laminating heat-sensitive documents, which would include faxes, photos, and documents printed with an ink jet printer. Cold lamination can be safer and provide better UV protection than hot lamination. Cold laminating pouches use an adhesive that is activated with pressure, are easy and safe to use because they do not get hot and may not use electricity.
Cold Roll Feed Laminators
Cold Roll Feed Laminators are used to laminate encapsulating film to mount prints to board, applying vinyl's and applying adhesive films. These are commonly used in-Copy and print shops, sign makers and commercial printers.
Single Hot Roll Feed Laminators
Single Hot Roll Feed Laminators encapsulate a heat activated thermal film being applied on one side of the print. The finished result is trimmed to leave a clear border around the edge of the print, therefore encapsulated. Film is available in gloss and matt finishes in a range of thickness from 42 - 250 micron.
Advantages of Flute Laminator
More Professional Look
Using laminating film will give your documents and materials a professional look, especially for name cards or posters. These items appear more polished and presentable, making them great for presentations or display in public areas. When someone takes the time to laminate items, it sends a message that the owner takes pride in their work.
Protect Your Documents
Laminating your documents, photos, and other materials by a laminator will ensure their durability. It's especially important for items that you handle frequently or use outdoors. The lamination acts as a shield against dirt, dust, grime, and fingerprints. Your laminated item can withstand the wear and tear of daily use without becoming damaged or discolored. This process seals your documents, photos, and other materials in a protective film that will keep them safe from water damage, dirt or grime.
Various Uses for Lamination
Different laminating film thicknesses can be used on a variety of documents, posters, and photos. The thicker laminating film, like a 10 mil laminating film, is extremely rigid and hard to bend. It's usually used for ID badges, reference sheets, and menus that do not need to fold. Thinner laminating film can be used on documents or posters that require folding or rolling.
Reusable Materials
Laminating is a cost-effective way to protect your documents and materials. Laminating machines and professional services are available at a range of prices, so you can find one that fits your budget. Additionally, lamination will help increase the lifespan of your items, preventing future costs associated with replacing them.
Features of Flute Laminator
Sensor Compensation Centering Device
The sensor compensation centering device uses multiple sets of sensors to sense the relative position of the running corrugated board so that the two servo motors on the left and right sides of the top paper are independently driven to achieve high-precision and high-speed centering of the top paper and the corrugated board.
Electronic Control System
The full-function electronic control system, touch screen, and PLC program automatically monitor the working status, which is convenient for troubleshooting. Electrical design conforms to CE standards.
Gluing Device
The gluing device adopts a high-precision gluing wheel and cooperates with a specially designed metering roller to improve the uniformity of gluing. Unique glue wheel, with glue stop device, and automatic glue level control system, to ensure that the glue does not overflow.
Frame
The frame is processed by a CNC lathe at one time, which ensures the accuracy of each position. Gear transmission, smooth operation, and low noise. The motors and spare parts are made by famous brands, with high efficiency, less trouble, and long service life.
Maintenance Tips for Flute Laminator
Turn It off First
You would think it would be the first thing to do, but some people have not followed this rule. Cleaning without turning off the machine could be disastrous.
Make Sure It Has Cooled Off
It is important to make sure the machine has cooled off before you start cleaning it. The reason is to protect yourself from getting burned and the other is it is easier to clean when the rollers have cooled down.
Never Use a Knife or Scissors
Don't try scraping any laminate that is stuck on your rolls. You can damage the rolls. It will leave nicks in the roller and cause creasing and air bubbles when you use it again. Don't use rubbing alcohol either, it can dry out your rollers.
Remove the Rollers for Cleaning
Put the machine into reverse to get any extra lamination out of the machine. It helps save time in the cleaning process. If there is an excess film on the rollers, you can warm up the rollers enough to make the excess film easy to clean. Use a clean cloth to rub off the film. You can use a rubber rejuvenator to help break down the glue.
Our Factory
Certificate & Honor
Ultimate FAQ Guide to Flute Laminator
Q: Which flute laminator is suitable for me?
Q: What are the advantages of laminating machine?
Q: Is the gluing thickness adjustable?
Q: How to choose a flute laminator?
Q: What safety features are included in a flute laminator?
Q: How to set time?
Q: Do I Need an operator to run this machine?
Q: What are the primary components of a Flute Laminator?
Q: What types of materials can a Flute Laminator handle?
Q: What are the benefits of using a Flute Laminator?
Q: What types of adhesives are used in Flute Laminators?
Q: Can a Flute Laminator produce different types of packaging structures?
Q: Can a Flute Laminator be integrated into a larger packaging production line?
Q: How do I stop my laminator from jamming?
Q: Do laminators have to heat up?
Q: Can I put paper through the laminator twice?
Q: Can I laminate the flute right after printing?
Q: Can I laminate and then cut?
Q: Do I need to leave an edge when laminating?
Q: How long do laminators last?
